Vehicle Type: Mobile Medical Vehicle
Number of Units: 1
Export Country: South Africa
Traveling mechanism: 6+12M Flat Frame Hyperchain Semi-trailer , FUWA 10T axle 5pcs, tires 235/70R17.5, 20+1pcs, air suspension, WABCO brake valve, FUWA28T legs, frame cross braces and side beams national standard steel, electrostatic adsorption high temperature paint
Clinic section：The vehicle is composed of two compartments, and the outside of the compartment is purchased with white paint-free plates, and the interior of the compartment is decorated with FRP plates. The interior of the compartment contains professional functional areas such as comprehensive outpatient clinics, mammography, gynecological examinations, digital DR imaging, dental diagnosis and treatment, vision refraction, hearing testing and standardized laboratories. 75 kW silent generator with Cummins engine.

The 20M Customized Combination Mobile Medical Trailer is a state-of-the-art, fully integrated mobile healthcare solution designed to deliver comprehensive medical services in remote, underserved, or emergency response areas. Built on a robust 6+12M flat frame hyperchain semi-trailer structure, it ensures exceptional stability and durability during transit.

The trailer is equipped with 5 pieces of FUWA 10T axles, 20+1 tires (235/70R17.5), air suspension, WABCO brake valves, and FUWA 28T landing legs for safe and smooth operation. Constructed with national standard steel cross braces and side beams, and finished with electrostatic adsorption high-temperature paint, the trailer offers superior strength, corrosion resistance, and long-term reliability.

The interior is intelligently divided into two main compartments, featuring exterior panels made of premium white paint-free plates and interior walls lined with easy-to-clean FRP (fiberglass-reinforced plastic) panels for hygiene and durability.

This mobile clinic is fully equipped with advanced medical facilities, including a comprehensive outpatient clinic, mammography and gynecological examination rooms, digital DR imaging, dental treatment unit, vision and hearing testing stations, and a standardized laboratory for on-site diagnostics.

Powered by a 75 kW silent diesel generator with a Cummins engine, the trailer operates independently of external power sources, making it ideal for field deployment.

Designed for rapid setup and high mobility, this mobile medical unit supports public health campaigns, rural healthcare outreach, disaster relief, and national screening programs, bringing hospital-level care directly to communities in need.
